Kinds of Jib Cranes
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes can transport loads between any areas within the boom's arc of rotation. Light duty units are used within factories and warehouses for loads weighing up to 5 tons. The BestJibCranes.com website showcases the major jib crane models as being either wall-mounted, mast mounted or free-standing.
Free Standing
The free-standing jib crane models do not require any support from the building structure and could stand by themselves. The horizontal boom in this situation is attached to a pivoting vertical column that is anchored solidly to the floor of the building. This kind of jib crane can rotate a full 360 degrees and requires a foundation made of either steel or concrete.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the top and the bottom. These pivots are attached to the floor of the building and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the advantage of not requiring the massive foundation required for free-standing units.
Wall Mounted
Wall mounted jib cranes are connected to the building wall instead of supporting a typical vertical column. These cranes provide a horizontal boom. These machinery are ideal in areas where the full 360 degree rotation is not required and provide up to 200 degrees of rotation.
There are two model varieties, depending on how the boom is supported. One of the kinds uses a tie rod that is attached from above the wall to the boom. The other variety supports the boom from below by utilizing a cantilever brace that is attached to the wall too.
