Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machines. They produce machines such as aerial lifts, manlifts and boom lifts. These machinery are designed to facilitate access to places that are difficult to reach, roofs and buildings, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves only in one direction and contains steps or handholds or paltforms that are attached to the unit to be able to move personnel from each floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions that measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is approximately 9 feet high by 8.5 feet wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
